VELP DK Series Kjeldahl Digestion Units

VELP DK Series Kjeldahl Digestion Units are developed for different applications, from the determination of nitrogen and protein according to the Kjeldahl method (TKN) in food analysis to the environmental analyses (Chemical Oxygen Demand) and chemical-pharmaceutical applications. VELP Offers a broad range of digesters including: DK 6, DK 6/48, DK8, and DK 20/26.

The aluminum block requires no maintenance and ensures a complete and homogeneous digestion, with high reliability. The DK Series includes a simple graphic display that guides the user in a simple and fast way, planning and monitoring the various digestion phases. 20 working programs are available with up to 4 temperature ramps for the simultaneous digestion of 6 (x 250 mL, Ø 42 mm, or x 300 mL, Ø 48 mm), 8 (x 250 mL, Ø 42mm) or 20 (x 100 mL, Ø26 mm) samples.

The whole series is provided with a wide range of options including temperature selection, programmable performance time, “continuous” working mode availability. All VELP digesters can be integrated with accessories to facilitate use.

A 20-position (250 mL tubes, Ø 42mm) and a 42-position for Micro-Kjeldahl (100 mL tubes, Ø 26 mm) digesters are also available. For more information on the dedicated leaflet.

Key Features

  • Friendly use – with just 4 keys, you can set different operations
  • High Accuracy – Temperature precision is ±0.5°C, with a quick heating speed
  • RS232 Interface – for PC data transfer and storage according to GLP
  • Safety – Electronic microprocessor checks and automatically calibrates the heating block’s temperature
  • Customizable – the operator can choose among 6 different languages
  • High-performance, high reliability for the preparation of your samples
  • Continuous innovation and dedication to taking care of the details
  • New support system and suction cups

Specifications for VELP DK Series Kjeldahl Digestion Units
Construction material: Epoxy painted with chemical resistant coating
Models: DK 6 6-position for 250 ml test tubes (Ø 42 mm)
DK 6/48 6-position for 300 ml test tubes (Ø 48 mm)
DK 8 8-position for 250 ml test tubes (Ø 42 mm)
DK 20 20-position for 250 ml test tubes (Ø 42 mm)
DK 20/26 20-position for 100 ml test tubes (Ø 26 mm)
DK 42/26 42-position for 100 ml test tubes (Ø 26 mm)
Set temperature: Digital readout in °C or °F
Countdown: Digital readout
Selectable language: UK, I, E, F, D, T
Power: DK 6 1100 W
DK 6/48 1100 W
DK 8 1350 W
DK 20 2300 W
DK 20/26 1100 W
DK 42/26 2300 W
Weight: DK 6 16.2 kg (35.7 lb)
DK 6/48 15.6 kg (34.4 lb)
DK 8 21.9 kg (48.3 lb)
DK 20 23.4 kg (51.6 lb)
DK 20/26 18.8 kg (41.4 lb)
DK 42/26 18.2kg (39.7 lb)
Dimensions (WxHxD):
(aluminum block only)
DK 6 293x152x339 mm (11.5x6x13.3 in)
DK 6/48 293x152x339 mm (11.5x6x13.3 in)
DK 8 233x152x448 mm (9x6x17.6 in)
DK 20 ?328x138x510 mm (12.9x5.4x20.1 in)?
DK 20/26 293x152x339 mm (11.5x6x13.3 in)
DK 42/26 328x138x510 mm (12.9x5.4x20.1 in)
Dimensions (WxHxD):
(aluminum block + support system)
DK 6 295x462x546 mm (11.6x18.2x21.5 in)
DK 6/48 295x462x546 mm (11.6x18.2x21.5 in)
DK 8 235x566x587 mm (9.3x22.3x23.1 in)
DK 20 328x702x585mm (12.9x27.6x23 in)
DK 20/26 295x462x546 mm (11.6x18.2x21.5 in)
DK 42/26 328x702x585mm (12.9x27.6x23 in)
PERFORMANCE
Temperature range: Ambient to 450 °C / 842 °F
Selectable ramps: up to 4 per program
Temperature Calibration: Automatic
Stability of the heating
block temperature:
± 0,5 °C
Precision of the heating
block temperature:
± 0,5 °C
Digestion time range: 1 to 999 minutes
Time selection: 1 minute steps
Filter
Item Attribute Description Model No. Power Unit of Measure Price Purchase
EF27422
F30100360
42-position for 100 mL test tubes DK42/26 230V/50-60 Hz Each
$6,649.95
In Stock
EF27421
F30110185
20-position for 100 mL test tubes DK20/26 115V/50-60 Hz Each
$4,865.95
In Stock
EF27420
F30100350
20-position for 250 mL test tubes DK20 230V/50-60 Hz Each
$13,864.95
In Stock
EF27418
F30110182
6-Position for 250 mL test tubes DK6 115V/50-60 Hz Each
$10,797.95
In Stock
EF27419
F30110020
8-position for 250 mL test tubes DK8 115V/50-60 Hz Each
$12,241.95
In Stock

With Selected Items:
